In the previous chapter, we explored key-value stores and their blazing-fast performance for simple lookups.

But what happens when you need that kind of scale for more structured data? What if you have billions of rows, each with potentially hundreds of columns, and you need to write millions of records per second while still querying efficiently?

This is the domain of wide-column databases. They originated from Google's Bigtable, created to handle the scale of Google's web indexing and analytics.

The ideas from Bigtable inspired Apache HBase and Apache Cassandra, which now power some of the largest systems in the world.

Wide-column databases sit somewhere between key-value stores and relational databases.

Like key-value stores, they partition data by key for horizontal scaling. But unlike simple key-value pairs, they organize data into column families, allowing you to store and retrieve groups of related columns efficiently.

The Wide-Column Data Model

The name "wide-column" can be confusing. It does not mean tables with many columns. It refers to a data model where each row can have a different set of columns, and columns are grouped into families that determine storage layout.

Rows, Columns, and Column Families

A wide-column table consists of:

Notice several key characteristics:

Sparse data

User 1001 has an email; user 1002 has a phone. User 1001 has three preferences; user 1002 has one. No storage is wasted on NULL values because columns are only stored when they have values.

Column families are fixed

You define column families at table creation. In the example, basic and preferences are the families.

Columns within families are dynamic

You can add new columns (like phone or timezone) without schema changes. Different rows can have completely different columns within a family.

Physical storage follows families

All columns in a family are stored together on disk. Reading the basic family does not require reading preferences.

Comparison with Relational Model

Two-Dimensional Key-Value

You can think of wide-column stores as two-dimensional key-value stores:

This two-level structure allows efficient access to specific columns without reading the entire row, which is valuable when rows have many columns.

Storage Architecture

Wide-column databases are optimized for write throughput. The key innovation is the Log-Structured Merge-tree (LSM tree), which converts random writes into sequential writes.

LSM Trees: Write Optimization

Traditional databases (like relational) use B-trees, which require updating data in place. This means random I/O for each write. LSM trees take a different approach:

Write path

Why this is fast:

Read Path

Reads are more complex because data might be in multiple locations:

Read amplification: In the worst case, a read might need to check multiple SSTables. Compaction reduces this by merging SSTables, but there is inherent trade-off between write and read performance.

Column Family Storage

Each column family is stored separately, like a mini key-value store:

This separation has important implications:

Cassandra

Apache Cassandra is the most widely deployed wide-column database. It was originally developed at Facebook for inbox search and is now used by Netflix, Apple, Uber, and many others.

Architecture

Cassandra uses a peer-to-peer architecture with no single point of failure:

Key characteristics:

Consistency Levels

Cassandra allows you to choose consistency on a per-query basis:

Strong consistency formula: If R + W > N, you get strong consistency, where:

For example, with RF=3 and QUORUM reads and writes (2 each), 2 + 2 = 4 > 3, so reads will always see the latest write.

CQL: Cassandra Query Language

Cassandra uses CQL, which looks like SQL but has significant limitations:

Key concepts:

What CQL Cannot Do

This is not a limitation of Cassandra. It is by design. These restrictions ensure queries can be executed efficiently in a distributed system.

HBase

Apache HBase is another major wide-column database, built on top of the Hadoop ecosystem. It was inspired directly by Google's Bigtable paper.

Architecture

Unlike Cassandra's peer-to-peer design, HBase uses a master-replica architecture:

Components:

HBase vs Cassandra

Choose HBase when:

Choose Cassandra when:

Data Modeling Patterns

Wide-column data modeling is fundamentally different from relational modeling. You design tables around your queries, not around entities.

Query-First Design

In relational databases, you normalize data and then figure out queries. In wide-column databases, you start with queries and design tables to serve them:

You will often have multiple tables storing the same data in different structures to serve different queries efficiently.

Time-Series Data

Wide-column databases excel at time-series data. A common pattern:

Why this works:

Denormalization

You must denormalize data to avoid joins. Store data redundantly in multiple tables:

Trade-off: More storage, more writes, but reads are fast and self-contained.

Bucketing

Prevent hot partitions by distributing data:

This spreads a user's data across multiple partitions, enabling parallel reads and preventing any single partition from becoming too large.

Materialized Views and Secondary Indexes

Some wide-column databases support these to reduce denormalization:

Cassandra Materialized Views:

The database automatically keeps the view in sync with the base table. However, this adds write latency and can cause consistency issues.

Secondary Indexes:

Secondary indexes have performance implications. They work well for low-cardinality columns but poorly for high-cardinality or frequently updated columns.

Compaction Strategies

Compaction is the process of merging SSTables to reduce read amplification and reclaim space from deleted data. Different strategies optimize for different workloads.

Size-Tiered Compaction (STCS)

Groups SSTables of similar size and merges them:

Pros: Good for write-heavy workloads, low write amplification.

Cons: Space amplification (may need 2x storage during compaction), can lead to many SSTables.

Leveled Compaction (LCS)

Organizes SSTables into levels with non-overlapping key ranges:

Pros: Bounded read amplification (check fewer SSTables), consistent read latency. Cons: Higher write amplification (data may be rewritten multiple times as it moves through levels).

Time-Window Compaction (TWCS)

Optimized for time-series data where old data is rarely modified:

Each time window gets its own SSTable. Old windows are never compacted together, making TTL-based deletion efficient (just delete the old SSTable file).

Pros: Efficient for time-series, great for TTL workloads. Cons: Requires data to be time-ordered, poor for updates to old data.

Performance Considerations

Partition Sizing

Partitions should be sized appropriately:

Rule of thumb: Aim for partitions under 100 MB and less than 100,000 rows.

Avoiding Hot Spots

Uneven data distribution causes hot spots:

Read vs Write Trade-offs

When to Choose Wide-Column

Wide-column databases are the right choice when:

When to Consider Alternatives

Wide-column databases may not fit when:

Summary

Wide-column databases extend the key-value model to handle structured data at massive scale:

Key design principles:

The next chapter explores graph databases, which take a fundamentally different approach by making relationships first-class citizens.
