When a user searches for "comfortable work from home chair" on an e-commerce site, they are not looking for those exact words.

They want results like "ergonomic office seating" or "lumbar support desk chair," even though these share no keywords with the query.

Traditional databases with keyword matching cannot solve this problem. They find exact matches, not semantic matches.

This is where vector databases come in. They store data as high-dimensional vectors called embeddings, which capture the meaning of text, images, or other data. Similar concepts end up close together in this vector space, even if they use different words or representations.

A vector database can find the most similar vectors to a query vector in milliseconds, enabling semantic search, recommendations, and AI-powered applications.

The rise of large language models (LLMs) like GPT has accelerated the importance of vector databases.

Understanding Embeddings

An embedding is a numerical representation of data in a high-dimensional space. Machine learning models learn to map text, images, audio, or other data types into vectors where similar items are close together.

How Embeddings Work

Consider text embeddings. An embedding model (like OpenAI's text-embedding-ada-002 or Sentence-BERT) converts text into a fixed-size vector:

The first two vectors are close together because the concepts are similar. The third is far away because running shoes are unrelated to office chairs.

Similarity Metrics

Vector databases use mathematical distance metrics to measure similarity:

Metric	Formula	Use Case
Cosine similarity	cos(θ) = (A·B) / (\|A\|\|B\|)	Text embeddings (normalized)
Euclidean distance	√Σ(ai - bi)²	General purpose
Dot product	A·B = Σ(ai × bi)	When magnitude matters

Cosine similarity is most common for text because it measures angle, not magnitude. Two vectors pointing in the same direction have similarity 1.0, regardless of their length.

Embedding Models

Different models produce embeddings for different data types:

Model	Dimensions	Data Type	Provider
text-embedding-ada-002	1536	Text	OpenAI
text-embedding-3-small	1536	Text	OpenAI
all-MiniLM-L6-v2	384	Text	Sentence Transformers
CLIP	512	Text + Images	OpenAI
Cohere embed	4096	Text	Cohere

More dimensions generally capture more nuance but require more storage and computation.

Vector Database Architecture

Vector databases are optimized for one primary operation: finding the K most similar vectors to a query vector (K-nearest neighbors, or KNN).

The Challenge

Consider a database with 10 million vectors of 1536 dimensions each:

Storage: 10M × 1536 × 4 bytes (float32) = 61 GB
Brute-force search: Compare query to all 10M vectors = too slow

For a single query, computing cosine similarity with all 10 million vectors takes seconds. Real-time applications need milliseconds.

Approximate Nearest Neighbors (ANN)

The solution is approximate algorithms that trade exactness for speed. Instead of finding the exact K nearest neighbors, they find vectors that are very likely to be among the nearest.

Approach	Exact KNN	Approximate KNN
Recall	100%	95-99%
Speed	O(n × d)	O(log n) to O(√n)
Use case	Small datasets, offline	Production, real-time

The metric "recall@K" measures what fraction of true K nearest neighbors are found. A recall of 0.95 means 95% of the true nearest neighbors are in the result set.

Indexing Algorithms

Vector databases use specialized indexes for fast ANN search:

Indexing Algorithms Deep Dive

HNSW (Hierarchical Navigable Small World)

HNSW is the most popular algorithm, offering excellent recall with fast queries. It builds a multi-layer graph where each layer is a sparser version of the layer below.

How HNSW search works:

Start at the top layer with the entry point
Greedily navigate to the closest node to the query
When no closer node exists, drop to the next layer
Repeat until reaching layer 0
Search more thoroughly in layer 0 to find K nearest

HNSW parameters:

Parameter	Effect
`M`	Connections per node. Higher = better recall, more memory
`efConstruction`	Search depth during build. Higher = better index, slower build
`efSearch`	Search depth during query. Higher = better recall, slower search

Pros: High recall, fast queries, works in-memory Cons: Memory-intensive, slow to build

IVF (Inverted File Index)

IVF partitions vectors into clusters and searches only relevant clusters:

How IVF search works:

Build time: Cluster vectors using k-means
Query time: Find nprobe nearest cluster centroids
Search only within those clusters for nearest neighbors

IVF parameters:

Parameter	Effect
`nlist`	Number of clusters. Higher = more partitions
`nprobe`	Clusters to search. Higher = better recall, slower

Pros: Lower memory than HNSW, scales to disk Cons: Lower recall at same speed, requires training step

Product Quantization (PQ)

Product quantization compresses vectors to reduce memory and enable disk-based search:

How PQ works:

Split vector into segments (e.g., 1536 dims → 192 segments of 8 dims)
For each segment, train a codebook of representative vectors
Replace each segment with the codebook ID of the nearest representative
Store only the IDs, not the full vectors

Compression ratio: 32x (float32 to 1-byte codes)

IVF-PQ: Combines IVF partitioning with PQ compression for large-scale, disk-based search.

Popular Vector Databases

Pinecone

Fully managed vector database service:

Deployment: Cloud-only (serverless or pod-based)
Scaling: Automatic horizontal scaling
Features: Metadata filtering, namespaces, hybrid search
Strengths: Zero operations, simple API

Milvus

Open-source vector database designed for scale:

Deployment: Self-hosted or Zilliz Cloud
Scaling: Distributed architecture, separates compute and storage
Features: Multiple index types, GPU acceleration, hybrid search
Strengths: Open source, highly scalable

Weaviate

Vector database with built-in vectorization:

Deployment: Self-hosted or Weaviate Cloud
Features: Built-in embedding models, GraphQL API, hybrid search
Strengths: Can vectorize data automatically, schema-based

Qdrant

Open-source vector database with filtering:

Deployment: Self-hosted or Qdrant Cloud
Features: Rich filtering, payload storage, quantization
Strengths: Fast filtered search, Rust-based performance

pgvector (PostgreSQL Extension)

Vector search as a PostgreSQL extension:

Deployment: Any PostgreSQL instance
Features: Full SQL, joins with other tables, transactions
Strengths: Use existing PostgreSQL infrastructure

Comparison

Feature	Pinecone	Milvus	Weaviate	Qdrant	pgvector
Managed	Yes	Optional	Optional	Optional	No
Open source	No	Yes	Yes	Yes	Yes
Built-in vectorization	No	No	Yes	No	No
SQL support	No	No	No	No	Full
Scaling	Automatic	Manual	Manual	Manual	Limited
Best for	Simplicity	Scale	Auto-vectorization	Filtering	SQL integration

Use Cases

Semantic Search

Find documents by meaning, not just keywords:

Typical implementation:

Pre-compute embeddings for all documents
Store embeddings with document IDs in vector database
At query time, embed the query
Find K nearest document embeddings
Return corresponding documents

Retrieval-Augmented Generation (RAG)

Give LLMs access to private knowledge:

Why RAG:

LLMs have knowledge cutoff dates
LLMs do not know your private data
LLMs can hallucinate; RAG grounds them in real documents
Cheaper than fine-tuning

Recommendations

Find similar items based on content or user behavior:

For collaborative filtering:

Image and Multimodal Search

Search images with text queries:

CLIP and similar models create aligned embeddings for text and images, enabling cross-modal search.

Anomaly Detection

Detect outliers by finding points far from their nearest neighbors:

Hybrid Search

Pure vector search can miss exact keyword matches. Hybrid search combines vector similarity with keyword matching:

Reciprocal Rank Fusion (RRF):

When to use hybrid:

Product search (exact model numbers + semantic description)
Technical documentation (exact terms + conceptual queries)
When recall is critical and you cannot miss exact matches

Performance Considerations

Memory vs Disk Trade-offs

Storage	Latency	Cost	Best For
In-memory (HNSW)	< 10ms	$$$	Small-medium datasets
Memory-mapped	10-50ms	$$	Medium-large datasets
Disk-based (IVF-PQ)	50-200ms	$	Very large datasets

Scaling Considerations

Factor	Impact	Mitigation
Vector count	Linear memory/storage	Quantization, sharding
Vector dimensions	Linear memory, √n search	Dimensionality reduction
Query throughput	CPU/GPU bound	Horizontal scaling
Index build time	O(n log n) typical	Incremental updates

Quantization

Reduce memory by compressing vectors:

Precision	Bytes/Dimension	Memory (1M × 1536)	Quality Impact
float32	4	6.1 GB	Baseline
float16	2	3.1 GB	Minimal
int8	1	1.5 GB	Small
Binary	0.125	192 MB	Significant

Most applications can use float16 or int8 with negligible quality loss.

When to Choose Vector Databases

Vector databases are the right choice when:

Semantic similarity matters. You want to find similar items by meaning, not exact match.
Building AI applications. RAG, semantic search, and AI-powered features need vector search.
Recommendations by content. Find similar products, articles, or content.
Unstructured data search. Search through text, images, audio, or video.

When to Consider Alternatives

Vector databases may not fit when:

Exact match is sufficient. If keyword search works, it is simpler.
Small scale. For < 100K vectors, pgvector or in-memory solutions may suffice.
No AI/ML component. If you are not using embeddings, you do not need a vector database.
Structured queries dominate. For filtering and aggregation, relational databases are better.

Summary

Vector databases enable similarity search over high-dimensional embeddings:

Aspect	Vector Database Approach
Data model	Vectors (embeddings) with metadata
Primary operation	K-nearest neighbor search
Indexing	HNSW, IVF, product quantization
Similarity	Cosine, Euclidean, dot product
Trade-off	Recall vs speed vs memory

Key concepts:

Embeddings: Neural network representations capturing semantic meaning
ANN (Approximate Nearest Neighbors): Trade exactness for speed
HNSW: Graph-based, high recall, memory-intensive
IVF-PQ: Clustering + quantization, scales to disk
Hybrid search: Combine vector and keyword for best results

The next chapter explores full-text search engines, which optimize for a different kind of search: keyword-based search with relevance ranking, faceted filtering, and linguistic analysis.
