Time-Series Databases
Last Updated: January 12, 2026
Every second, servers emit metrics. Every minute, IoT sensors send readings. Every millisecond, stock prices update. Every day, applications generate billions of log entries.
All of this data shares a common characteristic: it is timestamped, and time is the primary dimension for querying it.
This is time-series data, and it has unique properties that make general-purpose databases inefficient:
- Data arrives in time order and is rarely updated after insertion
- Queries almost always filter by time range
- Aggregations (averages, percentiles, sums) are more common than individual record lookups
- Recent data is accessed far more frequently than old data
- Data often has a natural retention period after which it can be deleted
Time-series databases are built specifically for these patterns. They use columnar storage for efficient aggregations, automatic data compression, and time-based partitioning that makes retention policies trivial to implement.
The result is databases that can ingest millions of data points per second while providing fast analytical queries.
Understanding Time-Series Data
Time-series data consists of observations recorded at specific points in time. Each observation typically includes:
- Timestamp: When the observation occurred
- Measurement: The value being recorded (temperature, CPU usage, price)
- Tags/Labels: Metadata identifying the source (server name, sensor ID, stock symbol)
Characteristics of Time-Series Data
| Property | Description |
|---|---|
| Immutable | Once written, data points are rarely modified |
| Sequential | Data arrives in time order (mostly) |
| High volume | Thousands to millions of points per second |
| Time-centric queries | Filters almost always include time range |
| Aggregation-heavy | Averages, sums, percentiles more common than point lookups |
| Compressible | Sequential data compresses well |
| Time-decaying value | Recent data is accessed more frequently |
Time-Series Data Model
Most time-series databases use a model with these concepts:
Series: A unique combination of metric name and tag set. For example, cpu.usage{host=server01, region=us-east} is one series.
Point: A timestamp-value pair within a series.
Field: The actual measured values (can have multiple fields per point).
This model allows efficient querying by time range within a series and aggregation across series that share tags.
Storage Architecture
Time-series databases use specialized storage engines optimized for sequential, time-ordered data.
Columnar Storage
Unlike row-oriented databases that store all columns of a row together, columnar storage stores each column separately:
Why columnar is better for time-series:
- Aggregations: Computing AVG(cpu) only reads the cpu column, not host or memory
- Compression: Values in a column are similar type, enabling better compression
- Vectorized operations: Modern CPUs can process column chunks efficiently
- Selective reading: Only load columns needed for the query
Time-Based Partitioning
Data is partitioned by time, typically into chunks covering fixed time intervals:
Benefits of time-based partitioning:
- Query efficiency: A query for "last hour" only reads recent partitions
- Retention: Delete old data by dropping entire partitions
- Hot/cold separation: Recent partitions on SSD, old on HDD or object storage
- Parallel processing: Different partitions can be queried in parallel
Compression Techniques
Time-series data compresses exceptionally well:
| Technique | Used For | Compression Ratio |
|---|---|---|
| Delta encoding | Timestamps (sequential) | 10-50x |
| XOR encoding | Floating-point values | 10-20x |
| Run-length encoding | Repeated values | Variable |
| Dictionary encoding | Tags with low cardinality | 10-100x |
| Block compression | General (LZ4, Zstd) | 2-10x |
Delta encoding example:
XOR encoding for floats: Consecutive floating-point values often share many bits. XOR encoding stores only the differing bits.
Write Path
Time-series databases optimize for high-volume writes:
- Buffer writes in memory: Incoming points go to a write buffer
- Write-ahead log: For durability, append to WAL before acknowledging
- Batch flush: Periodically flush buffer to compressed storage
- Background compaction: Merge small chunks into larger, more optimized files
This approach provides very high write throughput because:
- Memory writes are fast
- Batching amortizes I/O overhead
- Sequential writes to storage are efficient
Query Patterns
Time-series queries have distinctive patterns that databases optimize for.
Time-Range Filters
Almost every query includes a time-range predicate:
Time-series databases optimize these by:
- Using time-partitioned storage (only read relevant partitions)
- Indexing by time (fast range scans)
- Caching recent data (often in memory)
Aggregations
Aggregating values over time windows is the most common operation:
| Function | Use Case |
|---|---|
avg() | Average CPU usage |
max(), min() | Peak memory, lowest temperature |
sum() | Total requests, bytes transferred |
count() | Number of events |
percentile() | P99 latency |
rate() | Requests per second (from counter) |
derivative() | Rate of change |
Downsampling Queries
Aggregate old data into lower-resolution summaries:
Tag-Based Filtering
Filter by metadata before aggregating:
Time-series databases index tags for efficient filtering, typically using inverted indexes or bitmap indexes.
Retention and Downsampling
Managing data lifecycle is crucial for time-series databases.
Retention Policies
Define how long to keep data at each resolution:
Why tiered retention:
- Recent data needs high resolution for debugging
- Older data is typically viewed as trends, not individual points
- Storage costs grow linearly without downsampling
- Query performance improves with less data
Continuous Aggregation
Automatically maintain rollup tables as data arrives:
Storage Tiering
Move old data to cheaper storage:
| Tier | Storage | Use Case |
|---|---|---|
| Hot | SSD, Memory | Recent data, frequent queries |
| Warm | HDD | Older data, occasional queries |
| Cold | Object storage (S3) | Archive, rare access |
| Frozen | Tape, Glacier | Long-term compliance |
Popular Time-Series Databases
InfluxDB
Purpose-built time-series database with its own query language:
- Query language: InfluxQL (SQL-like) or Flux (functional)
- Data model: Measurements, tags, fields, timestamps
- Strengths: Developer experience, built-in dashboarding (InfluxDB Cloud)
- Use cases: DevOps monitoring, IoT, real-time analytics
Prometheus
Open-source monitoring system with built-in time-series database:
- Query language: PromQL
- Data model: Metrics with labels
- Architecture: Pull-based (scrapes targets)
- Strengths: Kubernetes-native, extensive ecosystem
- Use cases: Infrastructure monitoring, alerting
TimescaleDB
PostgreSQL extension for time-series data:
- Query language: SQL (standard PostgreSQL)
- Data model: Hypertables (auto-partitioned tables)
- Strengths: Full SQL, joins with relational data, PostgreSQL ecosystem
- Use cases: When you need time-series + relational in one database
QuestDB
High-performance time-series database focused on speed:
- Query language: SQL
- Strengths: Extremely fast ingestion and queries
- Use cases: Financial data, high-frequency trading, real-time analytics
Comparison
| Feature | InfluxDB | Prometheus | TimescaleDB | QuestDB |
|---|---|---|---|---|
| Query language | InfluxQL/Flux | PromQL | SQL | SQL |
| Write performance | High | Moderate | High | Very high |
| Query performance | High | High | High | Very high |
| Relational joins | No | No | Yes | Limited |
| Managed options | InfluxDB Cloud | Various | Timescale Cloud | QuestDB Cloud |
| Clustering | Enterprise | Thanos/Cortex | Enterprise | Planned |
| Best for | General TSDB | Monitoring | SQL compatibility | Speed |
Common Use Cases
Infrastructure Monitoring
Track server and application metrics:
Typical metrics:
- CPU, memory, disk, network utilization
- Request rate, latency percentiles, error rates
- Queue depths, connection counts
- Custom application metrics
IoT Sensor Data
Collect and analyze sensor readings:
Typical queries:
- Average temperature by location over the past week
- Devices exceeding threshold values
- Trend analysis for predictive maintenance
Financial Data
Track stock prices, trades, and market data:
Requirements:
- Millisecond or microsecond timestamp precision
- Very high ingestion rates (thousands of updates per second per symbol)
- Historical backtesting queries
- Real-time streaming
Application Analytics
Track user behavior and business metrics:
Typical queries:
- Daily active users over time
- Conversion rates by cohort
- Revenue trends by product category
Performance Considerations
Cardinality
Cardinality is the number of unique series (unique combinations of metric + tags). High cardinality is the most common performance problem:
| Cardinality Level | Example | Impact |
|---|---|---|
| Low | 100 servers, 50 metrics = 5,000 series | No problem |
| Medium | 10,000 containers, 100 metrics = 1M series | Manageable |
| High | 1M users, 50 metrics = 50M series | Problematic |
| Extreme | Using user ID as tag | Avoid! |
Why high cardinality hurts:
- Each series requires index entries
- Memory usage grows with series count
- Query performance degrades
Mitigation strategies:
- Never use high-cardinality values as tags (user IDs, email addresses)
- Move high-cardinality data to fields (not indexed)
- Pre-aggregate where possible
Write Performance Tuning
| Factor | Impact | Tuning |
|---|---|---|
| Batch size | Larger = fewer I/O ops | 1,000-10,000 points per batch |
| Buffer size | Larger = more memory, fewer flushes | Tune based on RAM |
| Compression | Slower writes, smaller storage | Usually worth it |
| Replication | Durability vs speed | Async if possible |
Query Performance Tuning
| Factor | Impact | Tuning |
|---|---|---|
| Time range | Wider = more data | Use shortest range needed |
| Tag filters | Selective = faster | Filter early, reduce series |
| Aggregation | Computed on read | Use pre-computed rollups for common queries |
| Concurrency | Resource contention | Limit concurrent queries |
When to Choose Time-Series Databases
Time-series databases are the right choice when:
- Time is the primary query dimension. Every query filters by time range.
- Data is append-heavy. Writes vastly outnumber updates to existing data.
- Aggregations dominate. You care about averages, sums, and percentiles, not individual records.
- Volume is high. Ingesting thousands to millions of points per second.
- Retention is time-based. Data naturally expires after a certain age.
When to Consider Alternatives
Time-series databases may not fit when:
- You need complex relationships. Time-series data is flat; use relational for joins.
- Updates are common. Time-series databases assume data is immutable.
- Point lookups dominate. Looking up specific records by ID is not the strength.
- Low volume. For small datasets, a regular relational database with time indexes works fine.
Summary
Time-series databases are optimized for timestamped data with predictable access patterns:
| Aspect | Time-Series Approach |
|---|---|
| Data model | Metrics with tags and timestamps |
| Storage | Columnar, time-partitioned, heavily compressed |
| Writes | Append-only, high throughput |
| Queries | Time-range filters, aggregations |
| Retention | Time-based expiration, downsampling |
Key concepts:
- Columnar storage: Efficient for aggregations, excellent compression
- Time partitioning: Query only relevant time ranges, easy retention
- Cardinality: Number of unique series; keep it manageable
- Downsampling: Reduce resolution of old data to save storage
The next chapter explores full-text search engines, which optimize for a different kind of search: keyword-based search with relevance ranking, faceted filtering, and linguistic analysis.
